HIGHLIGHTS

MSChart Extension - Zoom and Pan Control Version 2.2.0

MSChart Extension is an extension class for Microsoft Chart (MSChart) control in Visual Studio for WinForms applications. The tool was first published on July 2012 with the intention to overcome some of the limitation from the original MSChart and provide new functions. With zoom, pan and cursors added, the stock MSChart components can be use as an oscilloscope for waveform display and inspection.


Developer Toolbox
Engineering Toolbox
http://www.codearteng.com/search/label/TipsAndTricks

Popular posts from this blog

C# DSP Simulation - DSP Lab

Description DSP Lab is a digital signal processing simulation application created to simulate and visualize process of sampling and filtering analog signal using DSP system. This application is created to provide as a tool for educator and student to have a better understanding how DSP system works. DSP Lab allow you to view and listen to output from (Data Acquisition Unit) DAQ and digital filters.

DSP Toolbox is the core of DSP Lab application which is a .NET assembly written in C#. The library is released under MIT license. You can use this library to jump start your own DSP powered application.

DSP System DSP Lab is built using the system as shown below. Settings for each components are configurable.




In PREMIUM version, a 3 channels mixer system is available for more fun and signal combinations.
Read more

C# DSP Toolbox: Digital Filters (Updated)

Description
Digital filters classes are implemented in DSP (Digital Signal Processing) Toolbox from Version 1.5.0 onwards. Implemented filter types are as below:
Simple first order low-pass and high-pass filter.Simple second order band-pass and band-stop filter.Windowed FIR filter (Hanning, Hamming, Blackman) in low-pass and high-pass. Digital Filter Control: A WinForm based  user control is available for quick implementation in WinForm application.

Version 1.7.0
Added Filter size for FIR Windowed filters. Added Blackman Harris and Blackman Nuttall FIR Windowed filters.


Read more
